V1-D seriyali mashinalar
| Imkoniyat | 250-450 kg |
| O'rash | Yagona o'rash |
| Rotor | Ichki rotor |
| Pastki qism | U |
| Oyoq yostig'ining tekisligi | < 0,5 mm |
| Himoya reytingi | IP40 |
| Izolyatsiya klassi | F |
| polyaklar | 16 |
| Ish aylanishi | S5-25% |
| Tormoz | Plita |
| Tanlash/ushlab turish kuchlanishi | DC110V |
Tormoz uchun to'liq to'lqinli rektifikatsion quvvat manbai
| Model | Imkoniyat kg |
Lift tezligi Xonim |
Nominal chiqish kVt |
Nominal oqim Voltaj yoshi 220V |
Nominal oqim Kuchlanish yoshi 380V |
Nominal tezlik rpm |
Chastotasi Hz |
Shlangi diametri mm |
Moment Nm |
Arqonlar | Groove dist. mm |
Kesish burchagi | Chuqur burchak | Arqon bilan bog'lash | Mil yuki kg |
Tutqich g'ildiragi | Masofadan chiqarish | Inertsiya kg m^2 |
Og'irligi kg |
| VL-250-40-D | 250 | 0.4 | 0.67 | 6.1 | 3.5 | 76 | 10.2 | 200 | 83 | 3-P8 | 12 | b=90° | g=30° | 2:1 | 1500 | N | Y/N | 0.2 | 110 |
| VL-250-63-D | 0.63 | 1.1 | 120 | 16.0 | |||||||||||||||
| VL-250-100-D | 1.0 | 1.7 | 191 | 25.5 | |||||||||||||||
| VL-320-40-D | 320 | 0.4 | 0.85 | 7.4 | 4.3 | 76 | 10.2 | 200 | 105 | 3-P8 | 12 | b=90° | g=30° | 2:1 | 1500 | N | Y/N | 0.2 | 110 |
| VL-320-63-D | 0.63 | 1.3 | 120 | 16.0 | |||||||||||||||
| VL-320-100-D | 1.0 | 2.1 | 191 | 25.5 | |||||||||||||||
| VL-400-40-D | 400 | 0.4 | 1.1 | 9.9 | 5.7 | 76 | 102 | 200 | 133 | 3-P8 | 12 | b=90° | g=30° | 2:1 | 1500 | N | Y/N | 0.2 | 110 |
| VL-400-63-D | 0.63 | 1.7 | 120 | 16.0 | |||||||||||||||
| VL-400-100-D | 1.0 | 2.7 | 191 | 25.5 | |||||||||||||||
| VL-450-40-D | 450 | 0.4 | 12 | 11.2 | 6.5 | 76 | 102 | 200 | 150 | 4-P8 | 12 | b=90° | g=30° | 2:1 | 1500 | N | Y/N | 0.2 | 110 |
| VL-450-63-D | 0.63 | 1.9 | 120 | 16.0 | |||||||||||||||
| VL-450-100-D | 1.0 | 3.0 | 191 | 25.5 |
Eslatmalar:
1. Tormozni yig'ish / ushlab turish kuchlanishi DC110V. Voltajni o'zgartirish shart emas.
2.Regen haydovchi ilovasi, iltimos, biz bilan maslahatlashing, so'ngra eslatmalar bilan buyurtma bering.
