WR seriyali mashinalar
| Imkoniyat | 1600-2000 kg |
| O'rash | Yagona o'rash |
| Rotor | Ichki rotor |
| Pastki qism | U |
| Oyoq yostig'ining tekisligi | < 0,5 mm |
| Himoya reytingi | IP40 |
| Izolyatsiya klassi | F |
| polyaklar | 20 |
| Ish aylanishi | S5-40% |
| Dvigatel nominal kuchlanishi | AC380V |
| Tormoz | Plita |
| Tanlash/ushlab turish kuchlanishi | DC110V |
Tormoz uchun to'liq to'lqinli rektifikatsion quvvat manbai
| Model | Imkoniyat kg |
Lift tezligi Xonim |
Nominal chiqish KVt |
Nominal oqim A |
Nominal tezlik rpm |
Chastotasi Hz |
Shlangi diametri mm |
Moment Nm |
Arqonlar | Groove dist. mm |
Kesish burchagi | Chuqur burchak | Arqon bilan bog'lash | Mil yuki kg |
Tutqich g'ildiragi | Masofadan chiqarish | Inertsiya kg m^2 |
Og'irligi kg |
| ★WR-1600-100-D | 1600 | 1.0 | 9.7 | 23.0 | 119 | 19.9 | 320 | 775 | 10-P8 | 12 | b=90° | g=30° | 2:1 | 5000 | N | N | 1.40 | 500 |
| WR-1600-150-D | 1.5 | 16.0 | 42.0 | 179 | 29.8 | 851 | ||||||||||||
| WR-1600-160-D | 1.6 | 17.0 | 191 | 31.8 | ||||||||||||||
| WR-1600-175-D | 1.75 | 18.6 | 209 | 34.8 | ||||||||||||||
| WR-1600-200-D | 2.0 | 20.3 | 45.0 | 239 | 39.8 | 812 | ||||||||||||
| ★WR-2000-100-D | 2000 | 1.0 | 11.5 | 28.0 | 119 | 19.9 | 320 | 922 | 12-P8 | 12 | b=90° | g=30° | 2:1 | 5000 | N | N | 1.50 | 520 |
| WR-2000-150-D | 1.5 | 20.0 | 52.0 | 179 | 29.8 | 1064 | ||||||||||||
| WR-2000-160-D | 1.6 | 21.3 | 191 | 31.8 | ||||||||||||||
| WR-2000-175-D | 1.75 | 23.3 | 209 | 34.8 | ||||||||||||||
| ★WR-2000-200-D | 2.0 | 24.4 | 55.0 | 239 | 39.8 | 976 |
Eslatmalar: 1. Ushbu seriyaning standart dizayni faqat 180 ° o'rash burchagi uchun amal qiladi.
2. Bilan★belgisi, balans nisbati 0,45 ~ 0,5 ni tashkil qiladi.
3. Regen drive ilovasi, iltimos, biz bilan maslahatlashing, so'ngra eslatmalar bilan buyurtma bering.
